FLIR T1020 High-Definition Thermal Camera -40°C to 2000°C w/12° Lens and NIST Calibration

FLIR T1020-12-NIST || FLIR T1020 High-Definition Thermal Camera 1024 x 768 Resolution/30Hz, -40°C to 2000°C w/12° Lens and NIST Calibration

Get ready for outstanding thermal infrared performance, built on 50 years of experience. With its remarkable range, up to 3.1 MP in resolution, and customization to fit your needs, the T1K is designed to be the ultimate tool to streamline your workday, and make you the hero. For the sharpest images, the truest temperatures, the most flexibility – the T1K is the ultimate result of five decades of infrared expertise. Born out of five decades of infrared expertise, the FLIR T1K is designed for thermography experts who need the highest quality without compromise. Designed and built by FLIR, the OSX ™ Precision HDIR optical system provides unsurpassed image clarity, detail, and temperature accuracy, from wide angle to telephoto. With its dynamic focus control, continuous auto focus, and responsive user interface, the T1K definitely raises the bar on user-friendly performance. Its rugged, ergonomic design and rotating optical block take the stress out of a day-long list of inspections, making it easier to scan at difficult angles.

Specifications:

IR Sensor	1024 × 768 (786,432 measurement pixels)
Thermal Sensitivity/NETD	< 0.02°C at +30°C
Lens Choices	12°, 28°, 45°, 3x Close-up
Minimum Focus Distance	0.2m (0.66 ft.) to 0.8m (2.13 ft.), depending upon the lens
Image Frequency	30 Hz
Spectral Range	7.5 - 14 µm
4.3” Display	800 x 480 pixels
Auto Orientation	Yes
Touch Screen	Yes
Image Presentation Modes
Thermal Image	Yes
Visual Image	Yes
UltraMax ™	Unique super-resolution process quadruples pixel count, up to 3.1 MP
MSX ®	Embosses visual details on full resolution thermal image, for clear text and location identication
Gallery	Yes
Measurement
Accuracy	±2°C (±3.6°F) or 2%, whichever is greater, at 25°C (77°F) nominal
Measurement Analysis
Measurement Tools	10 spotmeters, 5+5 areas (boxes, circles) with min./max./average
Emissivity Correction	Variable from 0.01 to 1.0 or selected from materials list
Measurements Correction	Emissivity, reected temperature, relative humidity, atmospheric temperature, object distance, external IR window compensation
Color Palettes	Iron, Rainbow, Rainbow HC, White Hot, Black Hot, Arctic, Lava
Storage of Media
Storage Media	Removable SD card (Class 10)
Image File Format	Standard JPEG, including digital photo and measurement data
Video Recording/Streaming
Radiometric IR-Video Recording	Real-time radiometric recording to SD card
Non-Radiometric IR-Video Recording	H.264 to SD card
Radiometric IR-Video Streaming	Real-time radiometric streaming via USB
Non-Radiometric IR-Video Streaming	H.264 video using Wi-Fi or USB
Digital Camera
Digital Camera	FOV adapts to the IR lens
Video Lamp	Built-in LED light
Additional Information
USB, Connector Type	USB Micro-AB Data transfer to and from PC/Uncompressed colorized video
Battery	Rechargeable Li-ion polymer battery
Battery Operating Time	> 2.5 hours at 25°C (+68°F)
Charging System	In camera (AC adapter or 12 V from a vehicle) or 2-bay charger
Charging Time	2.5 hours to 90% capacity
External Power Operation	AC adapter, 90-260 VAC input, 50/60 Hz or 12 V output from a vehicle (cable with standard plug, optional)
Power Management	Automatic power-off functionality, user-congurable
Storage Temp. Range	-40°C to +70°C (-40°F to 158°F)
Weight	1.9 kg (4.3 lb.) to 2.1 kg (4.6 lb.), depending upon lens model
Tripod Mounting	UNC ¼”-20
