Bluetti Charger 1

Bluetti Charger 1

The Bluetti Charger 1 is a reliable, high-speed charging solution designed to keep your Bluetti power stations charged and ready on the road. Offering powerful output, safety features, and intelligent controls, it’s ideal for outdoor enthusiasts and those who rely on portable power.

Wide Device Compatibility

This versatile charger is compatible with all Bluetti power stations and most other brands, making it a convenient choice for users with multiple devices. Simply connect and charge seamlessly across a range of power stations.

High-Speed 560W Charging

Equipped with an impressive 560W output, the Charger 1 delivers energy six times faster than a standard car cigarette lighter charger, ensuring you’re ready for your next adventure without the wait. It’s perfect for quickly replenishing power stations on road trips, camping, or during unexpected outages.

Enhanced Cooling for Continuous Performance

Designed with an active fan cooling system, the Charger 1 maintains optimal performance and extends its service life by keeping temperatures low. This enhanced cooling system supports demanding, long-duration charges, making it especially useful for extended outdoor use.

Comprehensive Safety Features

The Charger 1 includes multiple safeguards to protect your vehicle battery and power station. Features like short-circuit protection, reverse connection prevention, and under-voltage/over-temperature alerts ensure safe and stable charging, so you can charge confidently on the go.

Smart Monitoring and App Control

Control the Charger 1 remotely with the Bluetti app to adjust voltage and monitor battery status in real time. It includes automatic on/off functionality to prevent vehicle battery drain, giving you full control over your charging needs with added peace of mind.

Specifications

OUTPUT

• Default Voltage: 27V

• Voltage Range with 12V Battery: 15.0V to 56.0V (adjustable via app)

• Voltage Range with 24V Battery: 27.0V to 56.0V (adjustable via app)

• Current: 10A

• Power: 560W

INPUT

• Voltage: 12V-14V / 22.5V-28V

• Amperage: 50A (12V) / 25A (24V)

GENERAL

• Function: Boost output voltage to charge power stations

• Compatibility: Bluetti power stations & most other brands

• Protections: Short circuit, anti-reverse, under-voltage, over-temp

• Cooling: Fan-cooled

• Surge Protection: 60A Circuit Breaker (optional)

• Operating Temp.: -20°C to 60°C (-4°F to 140°F)

• Protection Grade: IP20

• Noise Level: Max. 50dB

• Weight: 1.2 kg (approx. 2.65 lbs)

• Dimensions: 145 x 110 x 60 mm (5.7 x 4.3 x 2.4 in)

• Warranty: 2 Years

• App Connection: Bluetooth

What’s In The Box

1 x Charger 1 DC-DC Charger

1 x DC Input Cable

1 x MC4 Output Cable

4 x Hex Socket Screw

6 x Self-tapping Screw

1 x Hex Socket Wrench

4 x OT Terminal

2 x Tube Terminal (Red, Positive)

2 x Tube Terminal (Black, Negative)

1 x User Manual
