2x4 Video Wall Controller with 180 degree rotation (UHD-204VW)
UHD-204VW: 2x4 Ultra HD Video Wall Processor
Key Features:
- HDMI 2.0 and HDCP 2.2 compliant
- 2 Inputs and 4 Outputs with 2 HDMI Loop outputs
- Video resolution up to 4K@60Hz and 2K@60Hz
- Various video wall modes including 2x2
- Audio extraction through Analog outputs
- Bezel Compensation support
- 180-degree rotation for top 2 displays in 2x2 mode
- RS-232 and TCP/IP control
The UHD-204VW video wall controller is an awesome solution featuring 2 inputs, 4 outputs, and 2 loop outputs, catering to your media devices. It adheres to HDMI 2.0 and HDCP 2.2 standards, accommodating resolutions of up to 4K@60Hz and 2K@60Hz. Offering diverse video wall modes, including the versatile 2x2 mode, it allows for seamless bezel adjustment and provides a unique 180-degree rotation feature for the top two displays in 2x2 video wall mode. For audio extraction, it's equipped with a Mini Optical jack and a 5-pin L/R balanced output. Control options are extensive, with support for both RS-232 and TCP/IP connections, ensuring convenient management of your video wall setup.
[shortdes]
- Features 180 degree rotation for top two displays
- 2x2 Video Wall
- 2 HDMI Loop outputs
[/shortdes]
[tab]
CONNECTIVITY
| INPUT: | 2 × HDMI [Type A, 19-pin female] | |
| OUTPUT: | 6 × HDMI [Type A, 19-pin female] | |
| 1 × Mini Toslink [Optical Audio Jack] | ||
| 1 × L/R BALANCED OUT [5-pin ] | ||
| CONTROL: | 1 × RS-232 [3pin phoenix connector] | |
| 1 × RS232-CTL [3pin phoenix connector] | ||
| 1x LAN [RJ45, 8 Pin female] | ||
| 1x SERVICE [Micro USB, Update port] |
PACKAGE CONTENTS
| 1x UHD-204VW |
| 2x RS-232 3-pin Phoenix connector |
| 1x RS-232 5-pin Phoenix connector |
| 1x Power Adapter |
| User Manual |
SUPPORTED HDMI CABLES
| HDMI 2.0/ 2.1 | We recommend using high-quality HDMI 2.0/2.1 cables under 30 feet for optimum performance |
EXTENDING DISTANCE
| 4K@60Hz: | 30 Feet |
VIDEO OUTPUT
| Video Bandwidth: | 18 Gbps |
| Video Resolutions: | Up to 4K@60Hz and 2K@60Hz |
ADDITIONAL FEATURES
| CEC: | Yes |
| ARC: | No |
| USB KVM: | No |
| PoC/PoE: | No |
| IR Control: | Yes |
| Downmix: | No |
| Downscale: | No |
| Over IP: | No |
| HDBaseT: | No |
| RS-232: | Yes |
LOOP-OUT / LOCAL PORTS
| Has loop out port: | Yes |
| Number of Loop out ports: | 2 |
AUDIO SUPPORT
| HDMI Audio Formats: |
LPCM, Dolby, AC3, DTS
|
| 3.5mm Analog Audio Formats: |
PCM 2.0
|
COMPLIANCES
| HDMI Compliance | HDMI 2.0 |
| HDCP Compliance | HDCP 2.2 |
POWER
| Power Consumption: | 25W (Max) | |
| Power Supply: | Input: AC 100-240V 50/60Hz | |
| Output: DC 12V/3A |
DIMENSIONS & WEIGHT
| Length: | 218mm / 8.66in | |
| Width: | 146mm / 3.94in | |
| Height: | 43mm / 1.18in | |
| Weight: | 2kg / 4.41lbs |
PROPERTIES
| Color: | Black |
| Housing: | Metal Enclosure |
WARRANTY
| 1-Year Manufacturer's Warranty |
[/tab]
Original: $399.00
-70%$399.00
$119.70More Images
